2022 FRONTIER 700 6X6

2022 FRONTIER 700 6X6

The Frontier 700 6×6 sets out on every adventure with all the power of its 23 horsepower electronic fuel-injected (EFI) V-twin cylinder engine. The six-wheeled Frontier is the “entry-level” model of the Argo XTV line. Although it’s smaller than the larger Argos, the Frontier is designed with the same high standards of power, reliability, and go-anywhere courage. The Frontier 6×6 is fully amphibious, which of course means all of the following: dry land, wet land, mud, water, rocks, sand. With the new ITC Instant Torque Clutch and Argo Progressive Steering, the Frontier handles safely and smoothly on nearly any terrain.

2022 FRONTIER 700 6X6 Overview

  • 700 Series (23HP EFI) V-Twin Engine
  • Classic Transmission
  • ARGO Progressive Steering (APS)
  • New Instant Torque Clutch (ITC)
  • New Quieter Muffler
  • 24″ Tires
  • 8″ Steel Offset Rims
  • Rear Side Seats
  • Front Flat Floor
  • New 8.5 gal Steel Fuel Tank
  • New Fuel Level Display on Deluxe Gauge
  • Single Low Projector Beam Headlights
  • New Hi-Vis LED Brake/Taillights
  • HDPE Body Plastics
  • Axle Bearing Extensions

2022 FRONTIER 700 6X6 Colors

  • Green
  • Orange
  • Black

2022 FRONTIER 700 6X6 Specs

HORSEPOWER 23HP
CYLINDER V-TWIN
FUEL SYSTEM EFI
COOLING FAN COOLED
ALTERNATOR OUTPUT (MAX) 16 AMPS
SERVICE BRAKES HYDRAULIC
STEERING BRAKES HYDRAULIC
AUTO CHAIN LUBRICATION N/A
BRAKE COOLING FAN STANDARD
TRANSMISSION CLASSIC W/APS
DRIVE BELT STANDARD
FULL SKID PLATE STANDARD
BRUSHGUARD ACCESSORY
WINCH ACCESSORY
FRONT RACK ACCESSORY
BILGE PUMP STANDARD
ROPS N/A
STRETCHER FRAME N/A
REAR MESH N/A
ROOF N/A
POWER DUMP BOX N/A
LOAD CAPACITY – LAND 570 lb (258 kg)
LOAD CAPACITY – WATER 370 lb (1 68 kg)
TOWING CAPACITY 1,200 lb (544 kg)
SEATING CAPACITY – LAND 4
SEATING CAPACITY – WATER 2
FUEL CAPACITY 8.5 gal (32 L)
SPEED – LAND 22 mph (35 Km/h)
SPEED – WATER 3 mph (5 Km/h)
WEIGHT 970 lb (440 kg)
LENGTH (includes winch when standard) 96 in (2,439 mm)
WIDTH 58 in (1,473 mm]
HEIGHT 51 in (1,295 mm)
AXLE BEARING EXTENSIONS STANDARD
ENTRY STEP ACCESSORY
TIRES ARGO XT1 15 24X10-8
RIMS STEEL OFFSET
GROUND PRESSURE (18″ RUBBER TRACKS) 0.73 psi (5 kPa)
GROUND CLEARANCE (TIRES) 10 in (254 mm)
GROUND CLEARANCE (TRACKS) 11 in (279 mm]
WARRANTY 1 YEAR
COLORS GREEN, BLACK, ORANGE
