2022 Frontier 650 6×6

2022 Frontier 650 6×6

The six-wheeled Frontier is the “entry-level” model of the Argo XTV line. Although it’s smaller than the larger Argos, the Frontier is designed with the same high standards of power, reliability, and go-anywhere courage. The Frontier 6×6 is fully amphibious, which of course means all of the following: dry land, wet land, mud, water, rocks, sand. With the new ITC Instant Torque Clutch and Argo Progressive Steering, the Frontier handles safely and smoothly on nearly any terrain. The Frontier 650 6×6 packs a 23 horsepower carbureted V-twin engine and a new quieter muffler to conceal its presence.

2022 Frontier 650 6×6 Overview

  • 650 Series (23HP Carb)
  • Classic Transmission
  • ARGO Progressive Steering (APS)
  • New Instant Torque Clutch (ITC)
  • New Quieter Muffler
  • 24″ Tires
  • 8″ Steel Offset Rims
  • Rear Side Seats
  • Front Flat Floor
  • New 8.5 gal Steel Fuel Tank
  • New Fuel Level Display on Deluxe Gauge
  • Single Low Projector Beam Headlights
  • New Hi-Vis LED Brake/Taillights
  • HDPE Body Plastics

2022 Frontier 650 6×6 Colors

  • Green
  • Orange
  • Black

2022 Frontier 650 6×6 Specs

HORSEPOWER 23HP
CYLINDER V-TWIN
FUEL SYSTEM CARBURETOR
COOLING FAN COOLED
ALTERNATOR OUTPUT (MAX) 20 AMPS
SERVICE BRAKES HYDRAULIC
STEERING BRAKES HYDRAULIC
AUTO CHAIN LUBRICATION N/A
BRAKE COOLING FAN ACCESSORY
TRANSMISSION CLASSIC W/APS
DRIVE BELT STANDARD
FULL SKID PLATE STANDARD
BRUSHGUARD ACCESSORY
WINCH ACCESSORY
FRONT RACK ACCESSORY
BILGE PUMP STANDARD
ROPS N/A
STRETCHER FRAME N/A
REAR MESH N/A
ROOF N/A
POWER DUMP BOX N/A
LOAD CAPACITY – LAND 595 lb (270 kg)
LOAD CAPACITY – WATER 395 lb (179 kg)
TOWING CAPACITY 1,200 lb (544 kg)
SEATING CAPACITY – LAND 4
SEATING CAPACITY – WATER 2
FUEL CAPACITY 8.5 gal (32 L)
SPEED – LAND 22 mph (35 Km/h)
SPEED – WATER 3 mph (5 Km/h)
WEIGHT 945 lb (428 kg)
LENGTH (includes winch when standard) 96 in (2,439 mm)
WIDTH 58 in (1,473 mm]
HEIGHT 51 in (1,295 mm)
AXLE BEARING EXTENSIONS N/A
ENTRY STEP ACCESSORY
TIRES ARGO XT1 15 24X10-8
RIMS STEEL OFFSET
GROUND PRESSURE (18″ RUBBER TRACKS) 0.73 psi (5 kPa)
GROUND CLEARANCE (TIRES) 10 in (254 mm]
GROUND CLEARANCE (TRACKS) 11 in (279 mm]
WARRANTY 1 YEAR
COLORS GREEN, BLACK, ORANGE
